Downlight SIF-PV/P - 300/500 V
Application
Downlight SIF-PV/P is used for installation of downlight illumination. The cable is especially resistant towards the heat, the lighting of the downlight gives.
Construction
Conductor
Flexible Cu threads, class 5
Insulation
Silicone rubber El-2
Conductor color
Blue and brown
Outer sheath
Black PVC
Technical data
Working temperature
+90º C
Rated voltage
300/500 V
Test voltage
2000 V
Conductor temperature
-60º C to +180º C
Approvals
IEC 60332-1, CE, RoHS
Flame retardant acc. to IEC 60332-1
Flexible
Max. working temp. +90° C
| SKU | EAN | Dimension (mm2) | Current Value (A) | Winding | Diameter (mm)* | Weight (kg/km)* | |
|---|---|---|---|---|---|---|---|
| 410015012 | 5704403013326 | 2x1,5 | 14 | Sp-100 | 4,1x6,8 | 57 | |
